Surface-mounted door

The surface-mounted door has the same characteristics as the conventional hung door. However, the installation differs. Whereas the frame of hung doors is fixed in the opening (tunnel fitting), that of surface-mounted doors is attached to the masonry.

When should a surface-mounted door be chosen?

Opting for these doors is useful when renovating a building, for example if you wish to avoid altering the size of the opening but would like to create a wider passage. In fact, a surface-mounted door leaves the entire opening available for the passage.

Finishes and fittings

Basic fittings

  1. Door frame and leaf finish

    Magnelis® Hot-dip galvanised ZM 250 steel (250g/m², 20µm thick).

  2. Hinges

    Two screw-on steel hinges, adjustable and replaceable

  3. Handles

    A set of two U-shaped aluminium handles

  4. Lock and cylinder

    Standard 1-point lock with standard cylinder

  5. Cylinder backplate

    In PVC, decorative (the cylinder is flush with the door leaf)

  6. Dimensions

    Always made to measure

Optional fittings

  1. Door leaf finish

    Stainless steel 304, 316 / skinplate or RAL color *

  2. Door frame finish

    SStainless steel 304, 316 / skinplate or RAL color *

  3. Hinges

    One or more hinges can be added; these are always adjustable and replaceable

  4. Handles

    Handles, doorknobs, pull handles, etc. in aluminium or stainless steel

  5. Locks and closing systems

    No lock (door closers only) / manual, automatic, anti-panic, 1-point, 3-points or other locks on request / holding magnet

  6. Door closers

    With hinge or sliding arm, fitted on the hinge or non-hinge side, invisibly integrated door closer, closure selectors, open position maintained, etc.

  7. Ventilation

    Compliant ventilation grilles

  8. Various options

    Door leaf position indicator, non-removable security studs, soundproof doorsills, door stops, storm chains, impact plates and many other fittings.

  9. Glazing

    Standard or made-to-measure glazing for a largely glazed door (see glazing types available)

* RAL colors via our Partners
